StatisticsFH/FZ5 Processing Item Function Reference Manual
705
4
Support Inspection and Measurement
Key Points for Test Measurement and Adjustment (Statistics)
The following content is displayed in the "Detail result" area as text.
Key Points for Adjustment
Select the adjustment method referring to the following points.
When the measurement results are false
When the graph displays are false
Displayed items Description
Judge Judgement result
Calculated time Number of measurements performed
Statistical result 0 Statistical processing result of data 0
Statistical result 1 Statistical processing result of data 1
Statistical result 2 Statistical processing result of data 2
Statistical result 3 Statistical processing result of data 3
Statistical result 4 Statistical processing result of data 4
Statistical result 5 Statistical processing result of data 5
Statistical result 6 Statistical processing result of data 6
Statistical result 7 Statistical processing result of data 7
State Parameter to be adjusted Troubleshooting
Not all data is included in
th
e calculation
Data display
Data outside the judgement range will not be processed. If any
necessary da
ta is outside the judgement range, set the judgement
range again.
The measurement result
re
ma
ins 0.0
Statistical parameter
If the calculation timing is "Only when
the maximum number of
data is reached," the measurement result remains 0.0 while the
number of measurements is yet to reach the maximum number
saved. Change the calculation timing on the statistical parameter
tab to "Every time," and the measurement result will be calculated
every time.
State Parameter to be adjusted Troubleshooting
A graph showing a flat line
appears e
ven when the
value is changing.
Data display
Change the graph display range to an appropriate range. If the
in
itial va
lues remain unchanged, the display range is too wide and
the graph will show a flat line. Perform measurement at least
twice, and then click the default range button on the data display
tab.
