Image LoggingFH/FZ5 Processing Item Function Reference Manual
677
4
Support Inspection and Measurement
Key Points for Test Measurement and Adjustment (Image Logging)
The following content can be confirmed in the "Detail result" area using text.
Measurement Results for Which Output Is Possible (Image Logging)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Image Logging)
• If conditional branching is used, the number of files saved may vary from the specified number.
• If the operation mode is [Double Speed Multi-input mode], imag
es taken by odd-numbered measurements are
stored in a file different from one containing images taken by even-numbered measurements.
• If the operation mode is [Non-stop adjustment mode], the numbe
r
of files in the folder may vary from the specified
number before and after non-stop adjustment.
Displayed items Description
Judge Judgment result
Expression Calculation result of conditional expression
Measurement items Character string Description
Judge JG Judgment result
Data D00 Conditional expression data
Judge J00 Conditional expression Judgment
No. Data name Set/Get Data range
0 Judge Get only
0: No Judgment (unmeasured)
1: Judgment result OK
-1: Judgment result NG
5 Calculation result Get only -99999.9999 to 99999.9999
6 Judgement result Get only
0: No Judgment (unmeasured)
1: Judgment result OK
-1: Judgment result NG
120 Logging condition Set/Get
0: None
1: Only NG
2: All
121 Judge expression Set/Get Expression character string
122 to 123
Upper limit of conditions
calcul
ation
Set/Get -99999.9999 to 99999.9999
Lower limit of conditions
calcul
ation
Set/Get -99999.9999 to 99999.9999
124 Sub directory name Set/Get Character string
125 Prefix Set/Get Character string
Important
