Calc Axis Move by MultipointFH/FZ5 Processing Item Function Reference Manual
807
4
Support Inspection and Measurement
Measurement Results for Which Output Is Possible (Calc Axis Move by Multipoint)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
*1: The contents that can be output differ depending on the stage type.
: Output, : Do not output
Displayed item
Character
string
Description
Judge JG Judgment result
X axis movement MX X axis movement amount
Y axis movement MY Y axis movement amount
θ axis angle movement MT θ axis angle movement amount
*1
θ axis (linear drive) ML θ axis linear movement amount
*1
U axis movement MU U axis movement amount
V axis movement MV V axis movement amount
W axis movement MW W axis movement amount
R axis movement MR R axis movement amount
Position X difference DX Position X difference
Position Y difference DY Position Y difference
Angle difference DT Angle difference
Error max. MAXE Maximum error
Error min. MINE Minimum error
Error ave. AVEE Average error
Number of removed points RPN Number of removed points
Output contents XY XYθ θXY UVW UVWR X(Y) Xθ(Yθ) θX(θY) 3 axes 4 axes
θ axis angle
movement amoun
t


(θ axi
s
direct drive)

(
θ axis
di
rect drive)


(θ axis
direct drive)

(θ axis
dire
ct drive)

θ axis linear
movement amoun
t


(θ axi
s
line
ar drive)

(θ axis
li
near drive)
  

(θ axis
linear drive)

(θ axis
lin
ear drive)
 
