Set Unit Figure
654
FH/FZ5 Processing Item Function Reference Manual
Set Unit Figure
Used in the Following Case
When changing the measurement area based on the measurement results
Do not insert " Input image" processing items or " Compensate image" processing items between the " Set Unit Figure"
and the target processing unit.The processing unit figure may go out. The processing unit figure may go out.
Reference: Input image (p.23)
Reference: Compensate image (p.507)
[Search] After modifying the
Measurement region
[Search] Before modifying the
Measurement region
Measurement region
Example) Adjust the search measurement region based on the results of
edge position measurement.
Modifying
Important
