Classification
222
FH/FZ5 Processing Item Function Reference Manual
Measurement Results for Which Output Is Possible (Classification)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Classification)
Measurement items Character string Description
Judge JG Judgement result
Index IN Index No. with the highest correlation value
Model No. NO Model No. with the highest correlation value
Correlation value CR Correlation value with the model
Measurement position X X X coordinate of the position where
the model is detected
Measurement position Y Y Y coordinate of the position where
the model is detected
Measurement angle TH Angle of the position where the model is detected
Reference position X SX Reference coordinate X of the registered model
Reference position Y SY Reference coordinate Y of the registered model
Detection point RX RX X coordinate of the registered model
Detection point RY RY Y coordinate of the registered model
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Index Get only
-1: No models found
0 to 199
6 Model No. Get only
-1: No models found
0 to 4
7 Correlation value Get only 0 to 100
8 Measure X Get only -99999.9999 to 99999.9999
9 Measure Y Get only -99999.9999 to 99999.9999
10 Angle θ Get only -180 to 180
11 Reference X Get only -99999.9999 to 99999.9999
12 Reference Y Get only -99999.9999 to 99999.9999
13 Reference angle Get only -180 to 180
14 Detection coordinate X Get only -99999.9999 to 99999.9999
15 Detection coordinate Y Get only -99999.9999 to 99999.9999
101 Output Coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
103
Reflect to overall
j
udgement
Set/Get
0: ON
1: OFF
120 Search mode Set/Get
0: Correlation
1: Shape
121 With rotation Set/Get
0: OFF
1: ON
