Circle Regression
638
FH/FZ5 Processing Item Function Reference Manual
External Reference Tables (Circle Regression)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Central X Get only -99999.9999 to 99999.9999
6 Central Y Get only -99999.9999 to 99999.9999
7 Radius Get only 0 to 99999.9999
101 Output Coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
121 Number of points Set/Get 3 to 8
122 Method Set/Get
0: Nearest unit
1: Expression
130
Expressions (Point0
co
ordin
ate X)
Set/Get Exp. character string
131
Expressions (Point0
co
ordinateY)
Set/Get Exp. character string
132
Expressions (Point 1
co
ordin
ate Y)
Set/Get Exp. character string
133
Expressions (Point 1
co
ordinate Y)
Set/Get Exp. character string
134
Expressions (Point 2
co
ordinate X)
Set/Get Exp. character string
135
Expressions (Point 2
co
ordin
ate Y)
Set/Get Exp. character string
136
Expressions (Point 3
co
ordinate X)
Set/Get Exp. character string
137
Expressions (Point 3
co
ordinate Y)
Set/Get Exp. character string
138
Expressions (Point 4
co
ordin
ate X)
Set/Get Exp. character string
139
Expressions (Point 4
co
ordin
ate Y)
Set/Get Exp. character string
140
Expressions (Point 5
co
ordin
ate X)
Set/Get Exp. character string
141
Expressions (Point 5
co
ordin
ate Y)
Set/Get Exp. character string
142
Expressions (Point 6
co
ordinate X)
Set/Get Exp. character string
143
Expressions (Point 6
co
ordin
ate Y)
Set/Get Exp. character string
144
Expressions (Point 7
co
ordin
ate X)
Set/Get Exp. character string
145
Expressions (Point 7
co
ordinate Y)
Set/Get Exp. character string
