Image Conversion LoggingFH/FZ5 Processing Item Function Reference Manual
681
4
Support Inspection and Measurement
Area Setting (Image Conversion Logging)
Specify the range of images to be logged.
1 In the Item Tab area, click [Area Setting].
2 Use the drawing tools to specify the Image Conversion Logging range.
3 Click [OK] in the Figure setting area.
• [OK]: Changes the settings and returns to the previous menu.
• [Cancel]: Changes are discarded. R
eturns to the previous menu.
• [Apply]: Updates the settings without leaving edit window.
The range in which to perform logging is registered.
Key Points for Test Measurement and Adjustment (Image Conversion Logging)
The following content can be confirmed in the "Detail result" area using text.
Measurement Results for Which Output Is Possible (Image Conversion Logging)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
• If the operation mode is [Double Speed Multi-input mode], images taken by odd-numbered measurements are
stored in a file different from one containing images taken by even-numbered measurements.
• If the operation mode is [Non-stop adjustment mode], the numbe
r
of files in the folder may vary from the specified
number before and after non-stop adjustment.
Displayed item Description
Judge Judgement result
Expression Calculation result of conditional expression
Measurement items Character string Description
Judge JG Judgment result
Data D00 Conditional expression data
Judge J00 Conditional expression judgment
Important
To Next Page
