Circular Scan Edge Width
290
FH/FZ5 Processing Item Function Reference Manual
Measurement Results for Which Output Is Possible (Circular Scan Edge Width)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Circular Scan Edge Width)
Measurement items Character string Description
Judge JG Judgement result
Edge width Max. MAXW The maximum value of edge width
Edge width Min. MINW The minimum value of edge width
Edge width Ave. AVEW The average value of all the edge width
Lost width count LOST The number of the scanned areas for which the detection of width failed
Edge width Max. region No. MAXNO Region number of maximum edge width
Edge width Min. region No. MINNO Region number of minimum edge width
No. Data name Set/Get Data range
0 Overall judgement result Get only
1: OK
0: Not yet measured
-1: NG
5 Edge width Max. Get only 0 to 99999.9999
6 Edge width Min. Get only 0 to 99999.9999
7 Edge width Ave. Get only 0 to 99999.9999
10 Lost width count Get only 0 to 360
11
Region number of maximum edge
wi
dth
Get only 0 to 359
12
Region number of minimum edge
wi
dth
Get only 0 to 359
102 Calibration Set/Get
0: OFF
1: ON
103 Reflect to overall judgement Set/Get
0: ON
1: OFF
125 Region that displays the edge profile Set/Get 0 to 359
127 Fix region count Set/Get
0: Not fixed
1: Fixed
140 Width measure type Set/Get
0: Circle width
1: Diameter
141 Edge profile display direction Set/Get
0: Forward
1: Reverse
142 Upper limit of maximum edge width Set/Get 0 to 99999.9999
143 Lower limit of maximum edge width Set/Get 0 to 99999.9999
144 Upper limit of minimum edge width Set/Get 0 to 99999.9999
145 Lower limit of minimum edge width Set/Get 0 to 99999.9999
146 Upper limit of average edge width Set/Get 0 to 99999.9999
147 Lower limit of average edge width Set/Get 0 to 99999.9999
148
Upper limit of number of lost width
co
unt
Set/Get 0 to 360
