Control Flow NormalFH/FZ5 Processing Item Function Reference Manual
845
5
Branch
External Reference Table (Control Flow Normal)
By specifying a number, you can access the following data from processing items that support processing unit
data setting/acquisition, and from control commands.
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 State Get only
0: Flow not stopped
1: Flow stopped
103 Reflect to the overall judgement Set/Get
0: ON
1: OFF
120 Timeout Set/Get
0: Not used
1: Used
121 Timeout time (ms) Set/Get Timeout time (0 to 120,000)
122 Communication method Set/Get
0: RS-232C/RS-422
1: Ethernet
123 Unit judgement in timeout Set/Get
0: NG
1: OK
5000 Wait state clear command Set only 1: Clear the wait state
