Elapsed Time
690
FH/FZ5 Processing Item Function Reference Manual
Measurement Results for Which Output Is Possible (Elapsed Time)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Elapsed Time)
• Time elapse can be confirmed on the main screen "Detail result" area.
Measurement items Character string Description
Judge JG Latest processing unit judgement result
Elapsed Time TM Elapsed time from start of measurement (ms)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Elapsed Time Get only 0 to 999999
