Glue Bead Inspection
502
FH/FZ5 Processing Item Function Reference Manual
Key Points for Test Measurement and Adjustment (Glue Bead Inspection)
The following content is displayed in the "Detail result" area as text.
Key Points for Adjustment
Select the adjustment method referring to the following points.
When a path creation error occurs
When judgement is NG
Displayed items Description
Judge Judgement result
State Coated condition of measured coating
Min. width Maximum width of measured coating
Max. width Minimum width of measured coating
Gap width Gap width of measured coating
State Parameter to be adjusted Troubleshooting
Either the start position or end position
is set outside the measurement region.
Region setting
Set the start position or end position, whichever is
ap
plica
ble, inside the measurement region.
Either the start position or end position
is yet to be registered.
Region setting
Set the start position or end position, whichever is
ap
plica
ble.
Either the start position or end position
is inappropriate to fully enclose coating.
Region setting
Register the start position or end position,
wh
ichever is applicable, so that the two positions
are set vertically across coating.
Coating is gapped between the start
position
a
nd end position.
Region setting
If coating is gapped in the middle, register multiple
coat
ing gap inspections and set separate inspection
parts.
Width between paths of a spiral path
is sometimes measured.
Region setting
Divide the spiral into regions corresponding to
in
divid
ual turns and set a unit for each region.
State Parameter to be adjusted Troubleshooting
The judgement is NG (insufficient
memo
ry)
Region setting
Adjust the region so that the reference path
becomes shorter
.
