Edge Position
232
FH/FZ5 Processing Item Function Reference Manual
Key Points for Test Measurement and Adjustment (Edge Position)
The following content is displayed in the "Detail result" area as text.
The image specified in the Sub-image number in image display setting is displayed in the Image Display area.
Key Points for Adjustment
Select the adjustment method referring to the following points.
When the measurement results are unstable
Measurement Results for Which Output Is Possible (Edge Position)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
Setting item
Set value
[Factory default]
Description
Output coordinates
• [After scroll]
• Before scroll
As measurement results, select whether to output coordinate values
to external de
vices before or after the position compensation is
applied.
Calibration
• [OFF]
•ON
Select whether to reflect the calibration
in
the values output to the
external device as measurement results.
ON: Output the coordinates converted into actual dimensions.
OFF: Output the camera coordinate values.
Reflect to overall
ju
dgemen
t
• [ON]
•OFF
Enables choosing whether or not the judgement results of this
processing unit is reflected in the scene overall judgement.
Displayed items Description
Judge Judgement result
Edge position X X coordinate of the measured edge position
Edge position Y Y coordinate of the measured edge position
Sub image number Explanation of image to be displayed
0 Measurement image
1 Profile display
Parameter to be adjusted Remedy
Measurement
If the color of the edges to be detected is decided, specify the co
lor with [Edge color]. If results
are not stable even with the color specified, specify a larger value for the color variance range.
If noise is detected as an edge, specify larger values
for "Noise level" and "Noise width".
Measurement items Character string Description
Judge JG Judgement result
Edge position X X X coordinate of the measured edge position
Edge position Y Y Y coordinate of the measured edge position
Reference coordinate X SX Reference X
Reference coordinate Y SY Reference Y
