Glue Bead Inspection
504
FH/FZ5 Processing Item Function Reference Manual
External Reference Tables (Glue Bead Inspection)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Status of measure result Get only -
6 Min. width of measure result Get only -
7 Max. width of measure result Get only -
8
Average width of measure
resu
lt
Get only -
9 Lack width of measure result Get only -
10 Route len. (Long) Get only -
11 Route len. (Short) Get only -
101 Output Coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
103 Reflect to overall judgement Set/Get
0: ON
1: OFF
120 Register the max. color hue Set/Get 0 to 359
121 Register the min. color hue Set/Get 0 to 359
122
Register the max. color
sa
tu
ration
Set/Get 0 to 255
123
Register the min. color
sa
turation
Set/Get 0 to 255
124
Register the max. color
b
rightness
Set/Get 0 to 255
125
Register the min. color
b
r
ightness
Set/Get 0 to 255
126 Extract image Set/Get
0: OFF
1: ON
127 Background color Set/Get
0: Black
1 : White
2: Red
3: Green
4: Blue
128 With/without fill profile Set/Get
0: OFF
1: Fill profile
2: Filling up holes
129 Inverse area presence Set/Get
0: OFF
1: ON
130 With/without noise removal Set/Get
0: OFF
1: ON
131 Allowable path width Set/Get 2 to 100
132
Upper limit of the minimum
wi
d
th
Set/Get 0.0000 to 99999.9999
133
Lower limit of the minimum
wi
d
th
Set/Get 0.0000 to 99999.9999
