Glue Bead InspectionFH/FZ5 Processing Item Function Reference Manual
505
2
Inspecting and Measuring
134
Upper limit of the maximum
wid
th
Set/Get 0.0000 to 99999.9999
135
Lower limit of the maximum
wi
d
th
Set/Get 0.0000 to 99999.9999
136 Upper limit of average width Set/Get 0.0000 to 99999.9999
137 Lower limit of Average width Set/Get 0.0000 to 99999.9999
138 Upper limit of gap width Set/Get 0.0000 to 99999.9999
139 Lower limit of gap width Set/Get 0.0000 to 99999.9999
142 Upper limit of the binary level Set/Get 0 to 255
143 Lower limit of the binary level Set/Get 0 to 255
144 Binary image Set/Get
0: OFF
1: ON
145 Scanning direction for line 0 Set/Get
0: Clockwise
1: Counterclockwise
146 Scanning direction for line 1 Set/Get
0: Clockwise
1: Counterclockwise
147
Upper limit of the Route len.
(L
ong)
Set/Get 0.0000 to 99999.9999
148
Lower limit of the Route len.
(L
ong)
Set/Get 0.0000 to 99999.9999
149
Upper limit of the Route len.
(Short)
Set/Get 0.0000 to 99999.9999
150
Lower limit of the Route len.
(Short)
Set/Get 0.0000 to 99999.9999
151 Multiple selections Set/Get
0: Multiselect NG
1: MultiSelect OK
152 Display image type Set/Get
0: Measurement image
1: All color image
2: Color selected image
3: Binary image
153
Upper limit of the object area
ra
nge
Set/Get 0 to 999999999
154
Lower limit of the object area
ra
nge
Set
/Get 0 to 999999999
155 Labeling Set/Get
0: OFF
1: ON
156 Inspection kind Set/Get
0: Width's inspection only
1: Route's inspection only
2: Width and route's inspection
160 + N × 10
(
N = 0 to 7)
Flag N used for registered
color
Set/Get
0: OFF
1: ON
161 + N × 10
(N = 0 to 7)
Flag N for registered color OR/
NOT
Set/Get
0: OR
1: NOT
162 + N × 10
(N = 0 to 7)
Register the max. color hue N Set/Get 0 to 359
163 + N × 10
(
N = 0 to 7)
Register the min. color hue N Set/Get 0 to 359
164 + N × 10
(N = 0 to 7)
Register the max. color
saturation N
Set/Get
0 to 255
No. Data name Set/Get Data range
