Glue Bead Inspection
506
FH/FZ5 Processing Item Function Reference Manual
165 + N × 10
(N = 0 to 7)
Register the min. color
saturation N
Set/Get 0 to 255
166 + N × 10
(
N = 0 to 7)
Register the max. color
brightness N
Set/Get 0 to 255
167 + N × 10
(N = 0 to 7)
Register the min. color
brightness N
Set/Get 0 to 255
168 + N ×10
(N = 0 to 7)
Background color N Set/Get
0: Black
1: White
2: Red
3: Green
4: Blue
1000 + N × 2
(
N
= 0 to 1)
Min. width XN Get only -
1001 + N × 2
(
N = 0 to 1)
Min. width YN Get only -
1004 + N × 2
(
N = 0 to 1)
Max. width XN Get only -
1005 + N × 2
(
N
= 0 to 1)
Max width YN Get only -
1008 + N × 2
(
N = 0 to 1)
Gap pos. XN Get only -
1009 + N × 2
(
N = 0 to 1)
Gap pos. YN Get only
-
No. Data name Set/Get Data range
