Get Unit DataFH/FZ5 Processing Item Function Reference Manual
653
4
Support Inspection and Measurement
6 Click [OK].
The settings are finalized.
Measurement Results for Which Output Is Possible (Get Unit Data)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Get Unit Data)
• Only numeric data can be obtained for the processing unit data acquisition.
• To get character string data, use the macro customize functions.
• Those items whose data range are described as "Character String" in the external reference data list are
character strin
g
data.
• Clicking the desired data on the list enters the "Data No."
of the
clicke
d position.
• If ">" of "N" at the bottom of the
list is clicked, the "Data
No." with the N value of the number taken into account
can be set.
Measurement items Character string Description
Judge JG Judgement result
Data 00 to 15 DT00 to DT15 The values in the data 00 to 15
No. Data name Set/Get Data range
0 Judge Get only
0: No judgment (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 + N
(N = 0 to 15)
Data Get only -999,999,999.9999 to +999,999,999.9999
220 Number of acquired data Set/Get 1 to 16
221 + N
(N = 0 to 15)
Scene Set/Get
-1 to 9,999
If it is -1, refers to the current scene.
321 + N
(N = 0 to 15)
Unit Set/Get 0 to 9,999
421 + N
(N = 0 to 15)
Data No. Set/Get 0 to 99,999
Important
