Edge PositionFH/FZ5 Processing Item Function Reference Manual
225
2
Inspecting and Measuring
Settings Flow (Edge Positions)
Set the edge position with the following steps.
List of Edge Position Items
Item name Description
Region setting
This item is used to set up the measurement area.
Reference: Region Setting (Edge Position) (p.226)
Edge color
(for color cameras
only)
If the color of the edges to be detected is decided, specify the color.
Reference: Edge Color Specification - For Color Cameras Only (Edge Position) (p.227)
Ref. setting
The edge position is registered as the reference wh
en the regio
n is set. Change as necessary.
Reference: Reference Setting (Edge Positions) (p.227)
Measurement
This item specifies the judgement cond
ition for measurement results.
Measurement parameter can be changed as needed to
address unstable measurement results.
The displayed items depend on whether your camera is a color or monochrome camera. Normally,
the factory d
efault value will be used.
Reference: Measurement Parameters (Edge Positions) (p.229)
Output parameter
This item can be changed if necessary. Normally, the factory default value may be used.
Select the measurement result coordin
ates and set how to handle the coordinates.
Reference: Output Parameters (Edge Position) (p.231)
Necessary Steps Optional Steps
Verify/Adjust results
Region Setting (Edge Position)
Measurement Parameters (Edge Position)
Start
Settings completed
Test measurement
Output Parameters (Edge Position)
Reference Setting (Edge Position)
Edge Color Specification – For Color Cameras
Only (Edge Position)
