FH/FZ5 Processing Item Function Reference Manual
External Reference Tables (Intersection)
Long distance Max. of line 1 PMAXD1
The maximum distance between the approximate line and edge position
of l
ine 1 (plus direction)
Long distance Min. of line 1 PMIND1
The minimum distance between the approximate line and edge position
of
l
ine 1 (plus direction)
Short distance Max. of line 1 BMAXD1
The maximum distance between the approximate line and edge position
of
line 1 (minus direction)
Short distance Min. of line 1 BMIND1
The minimum distance between the approximate line and edge position
of
line 1 (minus direction)
Deviation of line 1 DEV1 Concave and convex deviation of line 1
Angle of line 1 LINETH1 The line 1's inclination against the measurement region
Lost point count of line 1 LOST1 Number of parts for which the detection of edges of line 1 has failed
Line parameter A of line 1 A1 A in the expression for the approximate line of line 1 AX + BY + C = 0.
Line parameter B of line 1 B1 B in the expression for the approximate line of line 1 AX + BY + C = 0.
Line parameter C of line 1 C1 C in the expression for the approximate line of line 1 AX + BY + C = 0.
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
1 Intersection coordinate X Get only -99999.9999 to 99999.9999
2 Intersection coordinate Y Get only -99999.9999 to 99999.9999
3 Angle Get only 0 to 180
4 Reference X
*1
Get only 0.0000 to 9999.0000
5 Reference Y
*1
Get only 0.0000 to 9999.0000
10 Peak edge position X of line 0 Get only 0.0000 to 99999.9999
11 Peak edge position Y of line 0 Get only 0.0000 to 99999.9999
12 Bottom edge position X of line 0 Get only 0.0000 to 99999.9999
13 Bottom edge position Y of line 0 Get only 0.0000 to 99999.9999
14 Edge position X Ave. of line 0 Get only -1.0000 to 99999.9999
15 Edge position Y Ave. of line 0 Get only -1.0000 to 99999.9999
16 Long distance Max. of line 0 Get only -1.0000 to 99999.9999
17 Long distance Min. of line 0 Get only -1.0000 to 99999.9999
18 Short distance Max. of line 0 Get only -1.0000 to 99999.9999
19 Short distance Min. of line 0 Get only -1.0000 to 99999.9999
20 Deviation of line 0 Get only -1.0000 to 99999.9999
21 Angle of line 0 Get only -180 to 180
22 Lost point count of line 0 Get only 0 to 100
23 Linear coefficient A of line 0 Get only -99999.9999 to 99999.9999
24 Linear coefficient B of line 0 Get only -99999.9999 to 99999.9999
25 Linear coefficient C of line 0 Get only -99999.9999 to 99999.9999
30 Peak edge position X of line 1 Get only 0.0000 to 99999.9999
Measurement items
Character
string
Description
