Shape Search IIIFH/FZ5 Processing Item Function Reference Manual
169
2
Inspecting and Measuring
Settings Flow (Shape Search III)
Set up shape search III according to the following steps.
List of Shape Search III Items
Item name Description
Model
This item registers the pattern chara
c
teristic of the measurement image as a model.
It changes the model parameter as necessary.
Reference: Model (Shape Search III) (p.170)
Region setting
This item is used to set up the measurement area.
Instead of measuring the entire input image, narrowin
g the
measurement area shortens the processing
time.
Reference: Region Setting (Shape Search III) (p.176)
Detection point
This item can be changed if necessary. It sets a position in
the model that should be used as the detection
coordinates during measurement. Usually, the central position of the set model is registered as the
detection coordinates.
Reference: Detection Point (Shape Search III) (p.177)
Ref. setting
This item can be changed if necessary. It sets the refere
nce positio
n within the camera's field of view.
Reference: Reference Setting (Shape Search III) (p.178)
Measurement
p
a
rameter
This item specifies the judgement condition for measur
ement results. Specify the criteria to judge the
measurement result if the X and Y coordinates and the correlation values with the model are OK.
Reference: Measurement parameter (Shape Search III) (p.179)
Output
p
arameter
This item can be changed if necessary. Normally
, the factory default value will be used.
Use the output parameter to specify how to handle th
e coordinates.
Reference: Output Parameter (Shape Search III) (p.183)
Make sure to set Set as necessary.
Check results/make adjustments
▲
Model (Shape Search III)
▲
Region Setting (Shape Search III)
▲
Measurement (Shape Search III)
▲
Detection Point (Shape Search III)
▲
Reference Setting (Shape Search III)
▲
Output parameters (Shape Search III)
Start
Settings complete
Test measurement
To Next Page
