Ec Corner
190
FH/FZ5 Processing Item Function Reference Manual
Ec Corner
This processing item measures a corner position (corner) of a work.
The intersection of two lines generated from the edge info
rmation of two sides of a square work is measured.
A desired corner can be measured by setting the length, d
irection, edge intensity and other conditions.
Used in the Following Case
When you want to align the work position based on the feature of its corner
Settings Flow (Ec Corner)
Set up EC corner according to the following steps.
Processing is different for color images and monochrome images. If the camera type, color camera, or monochrome
camera, was changed from a previous setup, a reset of some settings may be needed.
Important
Make sure to set Set as necessary.
Check results/make adjustments
Region Setting (Ec Corner)
Start
Line Extraction (Ec Corner)
Corner Extraction (Ec Corner)
Measurement Parameters (Ec Corner)
Settings complete
Test measurement
Output Parameters (Ec Corner)
Reference Setting (Ec Corner)
