Shape Search IIIFH/FZ5 Processing Item Function Reference Manual
189
2
Inspecting and Measuring
*1: The reference coordinates based on the selection in the Method area of the [Ref.setting] tab can be Get only.
*2: The reference coordinates based on the selection of Numerical in the Method area of the [Ref.setting] tab can be Set/Get.
180 Allowable distortion level Set/Get
0: Low
1: Medium
2: High
181 Noise removal level Set/Get 0 to 100
182
Display search model
imag
e
Set
/Get
0: OFF
1: ON
183 Complex background Set/Get
0: OFF
1: ON
227 Re-sort Set/Get
0: OFF
1: ON
228 Re-sort condition Set/Get
0: Correlation value ascending
1: Correlation value descending
2: X ascending
3: X descending
4: Y ascending
5: Y descending
229 Overlap judgement Set/Get
0: OFF
1: ON
230 Allowable overlap ratio Set/Get 1 to 100
231
Reference unit number
for re
fe
rence coordinate
Set/Get -1 to 9999
232
Reference type of
re
fe
rence coordinate
Set/Get
0: Set by number
1: Unit reference
233 Reference angle update Set/Get
0: Not update
1: Update
234
Reference unit number
for detection point
coord
i
nate
Set/Get -1 to 9999
235
Reference type of
detectio
n point coordinate
Set/Get
0: Set by number
1: Unit reference
236
Use coordinates before
po
si
tion compensation
Set/Get
0: Not used
1 : Used
237
Coordinate X before
po
si
tion compensation
Set/Get -99999.9999 to 99999.9999
238
Coordinate Y before
po
si
tion compensation
Set/Get -99999.9999 to 99999.9999
239
Angle before position
compensation
Set/Get -180 to 180
249 Show overlap judg. area Set/Get
0: OFF (Hide overlap judg. area)
1: ON (Show overlap jdug. area)
1000 + NN (NN = 0 to 127) Correlation value Get only 0 to 100
1100 + NN (NN = 0 to 127) Position X Get only -99999.9999 to 99999.9999
1200 + NN (NN = 0 to 127) Position Y Get only -99999.9999 to 99999.9999
1300 + NN (NN = 0 to 127) Measure angle Get only -180 to 180
30000 + NN (NN = 0 to 127) Correlation value Get only 0 to 100
40000 + NN (NN = 0 to 127) Edge position X Get only -99999.9999 to 99999.9999
50000 + NN (NN = 0 to 127) Edge position Y Get only -99999.9999 to 99999.9999
60000 + NN (NN = 0 to 127) Measure angle Get only
-180 to 180
No. Data name Set/Get Data range
