Calc Axis Move by MultipointFH/FZ5 Processing Item Function Reference Manual
805
4
Support Inspection and Measurement
: Show, : Hide
*1: Displayed only when the θ axis type is direct drive.
*2: Displayed only when the θ axis
type is linear drive.
Output Parameter (Calc Axis Move by Multipoint)
Set how the coordinates output to external equipment as measurement results are treated. Change this item as
needed. Normally, the factory default value will be used.
1 Click [Output parameter] in the Item Tab area.
2 Specify each of the following items.
V axis movement
amount
Judgement upper/lower
li
mi
t values
          
W axis movement
amoun
t
Judg
ement upper/lower
li
mi
t values
          
R axis movement
amount
Judgement upper/lower
li
mi
t values
          
Setting item
Setting value
[Factory default]
Description
Reflect to overall
judgemen
t
•[ON]
•OFF
Specify whether or not the judgement results of this processing unit is
reflected in the scene overall judgement.
Output type
• [Opposite moving]
• Absolute moving
Opposite moving: Calculates the movement amount fro
m the current axis
position.
Absolute moving: Calculates the movement amount from the origin.
Displayed content
Not
selected
XY XYθ θXY UVW UVWR X(Y) Xθ(Yθ) θX(θY) 3 axes 4 axes
