Label DataFH/FZ5 Processing Item Function Reference Manual
353
2
Inspecting and Measuring
3 When the setting has been changed,
click [Measure] in the Detail area to
verify whether measurements can be
made correctly.
4 Set up the judgement condition.
Output Parameters (Label Data)
Specify how to treat the coordinates to be output to the external device as measurement results. This item can
be changed if necessary. Normally, the factory default value will be used.
1 Click [Output parameter] in the Item Tab area.
2 Specify each of the following items.
Test Measurement (Label Data)
The following contents are displayed as text in the "Detail result" area.
• The values beside each item are measurement results of the displayed image. Take these values into
consideration to determine the upper and lower limit values.
Setting item Set value Description
Area 0 to 999999999.9999 Specify the area to be judged as OK.
Gravity X -99999.9999 to 99999.9999
Specify the range of X-axis shifting that is judged to be
OK.
Gravity Y -99999.9999 to 99999.9999
Specify the range of Y-axis shifting that is judged to be
OK.
• After setting up the measurement parameters, changing the output p
a
rameters will cause measurement results to vary
accordingly. If the output parameters have been changed, re-specify the measurement, too.
Setting item
Set value
[Factory default]
Description
Output coordinates
• [After scroll]
• Before scroll
As measurement results, select whether
to output coordinate values to
external devices before or after the position compensation is applied.
Calibration
•[OFF]
•ON
Select whether to reflect the calibration in the values output to the
external
device as measurement results.
ON: Output the coordinates converted into actual dimensions.
OFF: Output the camera coordinate values.
Reflect to overall
ju
dgemen
t
•[ON]
•OFF
Enables choosing whether or not the judgement results of this processing
unit is reflected in the scene overall judgement.
Displayed items Description
Judge Judgement result
Area Area
Gravity X Gravity X
Gravity Y Gravity Y
Note
Important
