Unit MacroFH/FZ5 Processing Item Function Reference Manual
617
4
Support Inspection and Measurement
Unit Macro
User's original measurement processing can be performed.
Unit macros are convenient if you want to build a ne
w measurement processing by combining filters and
measurement processing's, create a complex display that cannot be realized with the result display processing
items, or write original text in the detail text display.
Used in the Following Case
• Processing performed by multiple processing items such as looping and branching can be
consolidated into one.
Example) Perform search processing after carrying out filter processing multiple times
• Using a flow: Combine filtering, calculat
ion, Set Unit Data and search.
• Using unit macros: Add filtering and search to a flow and define a processing where search
measu
rement processing is performed after carrying out filter processing multiple
times.
A flow can be made simpler using unit macros.
For the specifications of the Unit Macro, and for det
a
ils on Unit Macro settings, refer to the following:
Reference: Description of the Setting Screen of the “Unit Macro” Processing Item and How to Configure
Settings in the V
ision System FH/FZ5 Series Macro Customize Functions Programming Manual (Cat. No. Z367)
• Unit Macros cannot be edited by remote operation.
