Camera Calibration
824
FH/FZ5 Processing Item Function Reference Manual
Measurement Results for Which Output Is Possible (Camera Calibration)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Camera Calibration)
Measurement
items
Character
string
Description
Judge JG Judgement result
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
2: Judgement result NG
5
Calibration parameter A (after
co
mp
ensation)
Get only -
6
Calibration parameter B (after
co
mpensation)
Get only -
7
Calibration parameter C (after
co
mpensation)
Get only -
8
Calibration parameter D (after
co
mp
ensation)
Get only -
9
Calibration parameter E (after
co
mpensation)
Get only -
10
Calibration parameter F (after
co
mpensation)
Get only -
11
X magnification ratio (after
co
mp
ensation)
Get only -
12
Y magnification ratio (after
co
mpensation)
Get only -
13 Origin X (after compensation) Get only -
14 Origin Y (after compensation) Get only -
15 X axis angle (after compensation) Get only -
16 Y axis angle (after compensation) Get only -
17 XY angle (after compensation) Get only -
120 Number of point specifications Set/Get 0 to 100
121 Operational point number Set/Get -1 to 99
130 Coordinate Set/Get
0: Right-hand type
1: Left-hand type
131 Origin Set/Get
0: Upperleft
1: Lowerleft
2: Center
3: Specify the coordinates
132 Magnification Set/Get 0.0001 to 9.9999
134 Camera coordinate X Set/Get -99999.9999 to 99999.9999
135 Camera coordinate Y Set/Get -99999.9999 to 99999.9999
136 Post-conversion coordinate X Set/Get -99999.9999 to 99999.9999
137 Post-conversion coordinate Y Set/Get -99999.9999 to 99999.9999
