Shape Search III
186
FH/FZ5 Processing Item Function Reference Manual
Measurement Results for Which Output is Possible (Shape Search III)
The measurement result of Shape Search III is the following. This result is displayed on the measurement result
area, and output to extra device is possible by using processing units related on output result.
Measurement items
Character
string
Description
Judge JG Judgement result
Number of detections C
Number of search items detected
If none detected, 0
Correlation value CR Correlation value with the model
Position X
*1
X X coordinate of the position where the model is detected
Position Y
*1
Y Y coordinate of the position where the model is detected
Angle θ TH Angle of the position where the model
is detected
Reference X SX X coordinate of the reference position of the registered model
Reference Y SY Y coordinate of the reference position of the registered model
Reference angle ST Angle of the registered model
Detection point RX RX X coordinate of the registered model
Detection point RY RY Y coordinate of the registered model
Correlation value N (N = 00 to
127)
CRN Detected search N correlation value (N = 00 to 127)
Position N (N = 00 to 127) XN Detected search N position X (N = 00 to 127)
Position N (N = 00 to 127) YN Detected search N position Y (N = 00 to 127)
Angle N (N = 00 to 127) THN Detected search N angle TH (N = 00 to 127)
