Position Data CalculationFH/FZ5 Processing Item Function Reference Manual
717
4
Support Inspection and Measurement
External Reference Tables (Position Data Calculation)
Calculation angle (Point 3-1) TH31 Angle created by connecting Point 3-1.
Calculation angle (Point 3-2) TH32 Angle created by connecting Point 3-2.
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Calculate position X Get only -99,999.9999 to 99,999.9999
6 Calculate position Y Get only -99,999.9999 to 99,999.9999
7 Calculation angle Get only -180.0000 to 180.0000
8 Calculate angle(point 0) Get only -
9 Calculate angle(point 1) Get only -
10 Calculate angle(point 2) Get only -
11 Calculate angle(point 3) Get only -
12 Calculate angle(point0-point1) Get only -
13 Calculate angle(point0-point2) Get only -
14 Calculate angle(point0-point3) Get only -
15 Calculate angle(point1-point0) Get only -
16 Calculate angle(point1-point2) Get only -
17 Calculate angle(point1-point3) Get only -
18 Calculate angle(point2-point0) Get only -
19 Calculate angle(point2-point1) Get only -
20 Calculate angle(point2-point3) Get only -
21 Calculate angle(point3-point0) Get only -
22 Calculate angle(point3-point1) Get only -
23 Calculate angle(point3-point2) Get only -
103 Reflect to overall judgement Set/Get
0: ON
1: OFF
120 Position calculation method:point 0 Set/Get
0: NOT checked
1: Checked
121 Position calculation method:point 1 Set/Get
0: NOT checked
1: Checked
122 Position calculation method:point 2 Set/Get
0: NOT checked
1: Checked
123 Position calculation method:point 3 Set/Get
0: NOT checked
1: Checked
124 Angle calculation method Set/Get 0 to 15
125 Upper limit of calculate position X Set/Get -99,999.9999 to 99,999.9999
126 Lower limit of calculate position X Set/Get -99,999.9999 to 99,999.9999
127 Upper limit of calculate position Y Set/Get -99,999.9999 to 99,999.9999
128 Lower limit of calculate position Y Set/Get -99,999.9999 to 99,999.9999
129 Upper limit of calculate angle Set/Get -180.0000 to 180.0000
Setting item
Character
string
Description
