Page #109 background imageLoading...
Page #109 background image
SearchFH/FZ5 Processing Item Function Reference Manual
107
2
Inspecting and Measuring
External Reference Tables (Search)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
-10: Error (image format mismatch)
-11: Error (unregistered model)
-12: Error (Insufficient memory)
-20: Error (Other error)
5 Correlation value Get only 0 to 100
6 Measure X Get only -99999.9999 to 99999.9999
7 Measure Y Get only -99999.9999 to 99999.9999
8 Measurement angle Get only -180 to 180
9 Reference X
*1
Get only -99999.9999 to 99999.9999
10 Reference Y
*1
Get only -99999.9999 to 99999.9999
11 Reference angle Get only -180 to 180
12 Detected coordinate X Get only -99999.9999 to 99999.9999
13 Detected coordinate Y Get only -99999.9999 to 99999.9999
14 Count Get only 0 to 128
101 Output Coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
103
Reflect to overall
jud
gemen
t
Set/Get
0: ON
1: OFF
120 Search mode Set/Get
0: Correlation
1: Shape
121 With rotation Set/Get
0: OFF
1: ON
122
Upper limit of the rotation
ang
le
Set/
Get -180 to 180
123
Lower limit of the rotation
ang
le
Set/
Get -180 to 180
124 Skipping angle Set/Get 1 to 30
125 Smart mode Set/Get
0: OFF
1: ON
126 Stab. (CR) Set/Get 1 to 15
127 Prec. Set/Get 1 to 3
128 Stab. (PT) Set/Get 1 to 5
129 Reference X
*2
Set/Get 0 to 99999.9999
130 Reference Y
*2
Set/Get 0 to 99999.9999
132 Detection point X Set/Get 0 to 99999.9999
133 Detection point Y Set/Get 0 to 99999.9999
134 Sub-pixel Set/Get
0: OFF
1: ON
135 Candidate Point Level Set/Get 0 to 100
