FH/FZ5 Processing Item Function Reference Manual
136 Upper limit of measure X Set/Get -99999.9999 to 99999.9999
137 Lower limit of measure X Set/Get -99999.9999 to 99999.9999
138 Upper limit of measure Y Set/Get -99999.9999 to 99999.9999
139 Lower limit of measure Y Set/Get -99999.9999 to 99999.9999
140 Upper limit of the angle Set/Get -180 to 180
141 Lower limit of the angle Set/Get -180 to 180
142 Upper limit of the corr. Set/Get 0 to 100
143 Lower limit of the corr. Set/Get 0 to 100
144 Save registered model Set/Get
0: OFF
1: ON
145 Candidate Point Level Set/Get 0 to 100
146 Sort order Set/Get
0: Correlation value ascending
1: Correlation value descending
2: X ascending
3: X descending
4: Y ascending
5: Y descending
147 Search No. Set/Get 0 to 127
148
Upper limit of count
jud
gemen
t
Set/Get 0 to 128
149
Lower limit of count
jud
gemen
t
Set/Get 0 to 128
150 Multiple output Set/Get
0: OFF
1: ON
151
Setting unit of reference
coord
i
nate
Set/Get -1 to 9,999
152
Setting type of reference
coord
i
nate
Set/Get
0: Numberical 1: Unit
153 Update the reference angle Set/Get
0: Not update 1: Update
154 Reference angle Set/Get -180 to 180
155
Setting unit of detection
coord
i
nate
Set/Get -1 to 9,999
156
Setting type of detection
coord
i
nate
Set/Get
0: Numberical 1: Unit
157
Use point coordinate
before
scroll
Set/
Get
0: Not use 1: Use
158 Position X before scroll Set/Get -99999.9999 to 99999.9999
159 Position Y before scroll Set/Get -99999.9999 to 99999.9999
160 Angle before scroll Set/Get -180 to 180
161 Count Set/Get 1 to 128
1000 + NN × 4
(NN = 0 to 31)
Correlation value Get only 0 to 100
1001 + NN × 4
(NN = 0 to 31)
Measure X Get only -99999.9999 to 99999.9999
1002 + NN × 4
(NN = 0 to 31)
Measure Y Get only
-99999.9999 to 99999.9999
No. Data name Set/Get Data range
