Ec CrossFH/FZ5 Processing Item Function Reference Manual
211
2
Inspecting and Measuring
Measurement Results for Which Output Is Possible (Ec Cross)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Ec Cross)
Measurement
items
Character
string
Description
Judge JG Judgement result
Cross coordinate X X Cross coordinate X
Cross coordinate Y Y Cross coordinate Y
Angle TH Angle
Number of
detections
CT Number of detections
Reference X SX Reference X
Reference Y SY Reference Y
Reference angle ST Reference angle
Cross coordinate
XN
(N = 0 to 99)
XN Cross coordinate XN
Cross coordinate
YN
(N = 0 to 99)
YN Cross coordinate YN
Angle N
(N = 0 to 99)
THN Angle N
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Number of detections Get only 0 to 10
6 Cross coordinate X Get only -99999.9999 to 99999.9999
7 Cross coordinate Y Get only -99999.9999 to 99999.9999
8 Angle Get only -45 to 45
9
Reference position X
coordin
ate
*1
Get only -99999.9999 to 99999.9999
10
Reference position Y
coordin
ate
*1
Get only -99999.9999 to 99999.9999
11 Reference angle Get only -180 to 180
101 Output Coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
103 Reflect to overall judgement Set/Get
0: ON
1: OFF
120 Edge level Set/Get 0 to 1000
