FH/FZ5 Processing Item Function Reference Manual
121 Filter size Set/Get
0: 3 × 3
1: 5 × 5
2: 7 × 7
3: 9 × 9
122 Lower limit of line length Set/Get 5 to 4000
123 Upper limit of line length Set/Get 5 to 4000
124 Combination angle Set/Get 0.0 to 30.0
125 Combination tip distance Set/Get 0 to 1000
126 Combination seam distance Set/Get 0 to 1000
127
Conditions for parallel line 0
Lower limit of length range
Set/Get 5 to 4000
128
Conditions for parallel line 0
Upper limit of length range
Set/Get 5 to 4000
129
Conditions for parallel line 1
Lower limit of length range
Set/Get 5 to 4000
130
Conditions for parallel line 1
Upper limit of length range
Set/Get 5 to 4000
138 Number of detection lines Set/Get 2 to 4
139
Conditions for parallel line 0
Lower limit of underrun range
Set/Get 0 to 1000
140
Conditions for parallel line 0
Upper limit of underrun range
Set/Get 0 to 1000
141
Conditions for parallel line 1
Lower limit of underrun range
Set/Get 0 to 1000
142
Conditions for parallel line 1
Upper limit of underrun range
Set/Get 0 to 1000
143
Conditions for parallel line 0
Min. width
Set/Get 1 to 1000
144
Conditions for parallel line 0
Max. width
Set/Get 1 to 1000
145
Conditions for parallel line 1
Min. width
Set/Get 1 to 1000
146
Conditions for parallel line 1
Max. width
Set/Get 1 to 1000
148 Detection object color Set/Get
0: Both
1: Cross (dark) - Background (light)
2: Cross (light) - Background (dark)
156 Sort order Set/Get
0: Cross X
1: Cross Y
2: Line length
157 Sort sequence Set/Get
0: Ascending
1: Descending
158 Output number Set/Get 0 to 99
162 Fusion distance Set/Get 0 to 1000
163
Judgement condition: Lower
limit of
cross X
Set
/Get -99999.9999 to 99999.9999
164
Judgement condition: Upper
limit of
cross X
Set/Get
-99999.9999 to 99999.9999
