Display Last NG ImageFH/FZ5 Processing Item Function Reference Manual
887
7
Display result
Measurement Results for Which Output Is Possible (Display Last NG Image)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Display Last NG Image)
Measurement items Character string Description
Judge JG Judgement result
Judge data 00 to 07 JD 00 to 07 Calculation data 00 to 07 for inclusion 0
Judge judge 00 to 07 JJ 00 to 07 Calculation judgment 00 to 07 for inclusion 0
Last NG data 00 to 15 D000 to 15 NG data 00 to 15
Last NG judge 00 to 15 J000 to 15 Judge NG 00 to 15
Last 1 NG data 00 to 15 D100 to 15 Last N NG data 00 to 15
Last 1 NG judge 00 to 15 J100 to 15 Last N NG judge 00 to 15
Last 2 NG data 00 to 15 D200 to 15 Last N NG data 00 to 15
Last 2 NG judge 00 to 15 J200 to 15 Last N NG judge 00 to 15
Last 3 NG data 00 to 15 D300 to 15 Last N NG data 00 to 15
Last 3 NG judge 00 to 15 J300 to 15 Last N NG judge 00 to 15
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 to 12
Judge data N
(N = 0 to 7)
Set/Get -999999999.9999 to 999999999.9999
13 to 20
Judge judge N
(N = 0 to 7)
Set/Get
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
103
Reflect to overall
judg
ement
Set
/Get
0: ON
1: OFF
120 Judgement mode Set/Get
0: One NG
1: All NG
121 Save type Set/Get
0: Image
1: Image + data
122 Number of logging Set/Get 1 to 4
123
Target processing unit
numbe
r
Set
/Get
-1 to 9999
-1: Save the image of itself
124 Image memory setting flag Set/Get
0: OFF
1: ON
140 to 147
Condition exp N
(N = 0 to 7)
Set/Get Exp character string for inclusion processing unit 0
148 to 163
Upper limit of condition
calcul
ati
on M
(M = 0 to 15)
Set/Get
Even number is upper limit, odd number is lower limit
Exp upper and lower limits for inclusion processing unit 0
Lower limit of condition
calcul
ation M
(M = 0 to 15)
Set/Get
