Date VerificationFH/FZ5 Processing Item Function Reference Manual
409
2
Inspecting and Measuring
Test Measurement (Date Verification)
The following content is displayed in the "Detail result" area as text.
Measurement Results for Which Output Is Possible (Date Verification)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Date Verification)
Displayed items Description
Judge Judgement result
Target string Target string setting is displayed.
Read string A character string read from the OCR unit is displayed.
Measurement items Character string Description
Judge JG Judgement result
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
1 Verification string Get only Character string with 32 characters or less
2 Read string Get only Character string with 32 characters or less
103
Reflect to overall
judg
ement
Set/Get
0: ON
1: OFF
120 OCR unit number Set/Get
-1: OFF
0 to 9999
125 Term year Set/Get 0 to 99
126 Term month Set/Get 0 to 99
127 Term day Set/Get 0 to 999
128 Auto Update Set/Get
0: Not update
1: First measurement after startup
2: Always update
129 Zero suppress Set/Get
0: 0
1: Space
130 Calculation order Set/Get
0: Month→Da
y
1:
Day→Month
131 Month end adjust Set/Get
0: Last day of now
1: First day of next
2: Gap day of next
132 Back margin Set/Get 0 to 99
133 Ahead margin Set/Get 0 to 99
134 Code year 1 flag Set/Get
0: Not used
1 : Used
135 Code year 2 flag Set/Get
0: Not used
1 : Used
