Trend MonitorFH/FZ5 Processing Item Function Reference Manual
671
4
Support Inspection and Measurement
The image specified in the Sub-image number in image display setting is displayed in the image display area.
Measurement Results for Which Output Is Possible (Trend Monitor)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
Minus σ
Average of measurement values during period recorded
- standard deviation of the
measurement values
Minus 3σ
Average of measurement values during period re
corded
- standard deviation of the
measurement values × 3
Measurement count Measure count since the beginning of measurement
OK count
Number of measurements since starting to make measurements - NG count in number of
mea
s
urements
NG count Number of NG occurrences withi
n the
measurement count
Warning count Warning count within the measurement count
Yield
OK count in number of measurements / Number of
measurements since starting to make
measurements
Sub image number Explanation of image to be displayed
0 Trend graph
1 Histogram
Measurement items Character string Description
Judge JG Judgement result
Measurement DT Latest measured value
Warning WN Existence of warning occurrence
Maximum MX Max. measurement value during recording period
Minimum MN Min. measurement value during recording period
Deviation DV Standard deviation for measurement values during recording period
Plus 3σ AP3
Average of measurement values during period recorded + standard
deviati
on of the measurement values × 3
Plus σ AP1
Average of measurement values during period recorded + standard
devia
ti
on of the measurement values
Average AV Average value for measurement values during recording period
Minus σ AM1
Average of measurement values during period recorded - standard
devia
ti
on of the measurement values
Minus 3σ AM3
Average of measurement values during period recorded - standard
devia
ti
on of the measurement values × 3
Measurement count MC Measure count since the beginning of measurement
OK count OC
Number of measurements since starting to make measurements - NG
count in nu
mb
er of measurements
NG count NC Number of NG occurrences within the measurement count
Warning count WC Warning count within the measurement count
Yield YD
OK count in number of measurements
/ Number of measurements since
starting to make measurements
Displayed items Description
