EC Circle SearchFH/FZ5 Processing Item Function Reference Manual
153
2
Inspecting and Measuring
Key Points for Adjustment
Select the adjustment method referring to the following points.
When the measurement results are unstable
When the processing speed is slow
Measurement Results for Which Output Is Possible (EC Circle Search)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
Parameter to be adjusted Processing
Measurement If images that should be judged OK vary greatly, specify a smaller value for "Evaluation".
Circle setting
Mask any unnecessary items.
Lower the edge level.
Parameter to be adjusted Processing
Region setting Make the search region as small as possible.
Measurement If images that should be judged OK vary little, specify a larger value for "Evaluation".
Measurement items Character string Description
Judge JG Judgement result
Measurement coordinate X X X coordinate of the position where
the circle is detected
Measurement coordinate Y Y Y coordinate of the position where
the circle is detected
Reference position X SX X coordinate of the reference position of the registered circle
Reference position Y SY Y coordinate of the reference position of the registered circle
EC correlation value CR Evaluated value of circle detected
Radius RA Radius of circles detected
Count CT Quantity of circles detected
Position N XN Detected circle N position X (N = 0 to 255)
Position N YN Detected circle N position Y (N = 0 to 255)
Evaluation N CRN Detected circle N circle evaluated value (N = 0 to 255)
Radius N RAN Detected circle N circle radius (N = 0 to 255)
