Line RegressionFH/FZ5 Processing Item Function Reference Manual
633
4
Support Inspection and Measurement
Measurement Results for Which Output Is Possible (Line Regression)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Line Regression)
Measurement items Character string Description
Judgement JG Judge
Line Param. 0 A Parameter A of line 0
Line Param. 0 B Parameter B of line 0
Line Param. 0 C Parameter C of line 0
Line Param. 1 A1 Parameter A of line 1
Line Param. 1 B1 Parameter B of line 1
Line Param. 1 C1 Parameter C of line 1
Cross point X CX X coordinate of intersection
Cross point Y CY Y coordinate of intersection
Angle TH Angle between two lines
Point X PX X coordinate of input point
Point Y PY Y coordinate of input point
Distance DS Distance between line 0 and input point
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Line Param. 0 A Get only -99999.9999 to 99999.9999
6 Line Param. 0 B Get only -99999.9999 to 99999.9999
7 Line Param. 0 C Get only -99999.9999 to 99999.9999
8 Line Param. 1 A Get only -99999.9999 to 99999.9999
9 Line Param. 1 B Get only -99999.9999 to 99999.9999
10 Line Param. 1 C Get only -99999.9999 to 99999.9999
11 Cross point X Get only -99999.9999 to 99999.9999
12 Cross point Y Get only -99999.9999 to 99999.9999
13 Angle Get only 0.0000 to 180.0000
14 Point X Get only -99999.9999 to 99999.9999
15 Point Y Get only -99999.9999 to 99999.9999
16 Distance Get only 0.0000 to 99999.9999
101 Output Coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
120 Function type Set/Get
0: Calculate line
1: Calculate cross point and angle of two lines
2: Calculate distance between line and point
