Camera Image Input HDR
76
FH/FZ5 Processing Item Function Reference Manual
HDR Settings (Camera Image Input HDR)
Specify the image combination method etc.
1 In the Item Tab area, click [HDR setting].
2 In the "Mode select" area, specify the mode.
When you select the mode in the "Mode select" area and specify the measurement region on the image,
the parameters are set automatically. To finely adjust the parameters, refer to the next items.
Do not perform next camera image input processing before STGOUT signal output is completed. STGOUT signal may not
be output.
Perform camera image input processing after STGOUT signal o
u
tput completion, or set the STEP-camera delay,
STEPSTGOUT delay and STGOUT pulse width so that the electronic flash operates synchronizing with the exposure time.
STGOUT signals are output at each imaging. Therefore,
it can be duplicated with the next STGOUT signal output,
depending on the STEP-STGOUT delay or STGOUT width settings.
If it duplicates with the next, the numbe
r
of times for imaging and electronic flashing can differ.
Item
Set value
[Factory default]
Description
Mode
select
[HDR mode]
In halation is likely generated image, select this mode if you want to stabilize the
brightness.
Generate images with stable brightness by sh
ooting
multiple images with different
shutter speeds based on the set Bright range.
High contrast mode
Select this mode if you want to generate image with good contrast.
Generate images with good contrast by shooti
ng multiple images with different
shutter speeds based on the set Average and Width.
To Next Page
