Shape Search IIIFH/FZ5 Processing Item Function Reference Manual
187
2
Inspecting and Measuring
External Reference Tables (Shape Search III)
Setting the number of Processing unit data setting / Control command or acquisition function, you can refer the
following data.
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
-10: Error (image form
at mismatch)
-1
1: Error (unregistered model)
-12: Error (Insufficient memory)
-20: Error (Other error)
5 Correlation value Get only 0 to 100
6 Position X Get only -99999.9999 to 99999.9999
7 Position Y Get only -99999.9999 to 99999.9999
8 Measure angle Get only -180 to 180
9 Reference position X
*1
Get only -99999.9999 to 99999.9999
10 Reference position Y
*1
Get only -99999.9999 to 99999.9999
11 Reference angle Get only -180 to 180
12 Detection coordinate X Get only -99999.9999 to 99999.9999
13 Detection coordinate Y Get only -99999.9999 to 99999.9999
14 Count Get only 0 to 128
101 Output Coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
103
Reflect to overall
ju
dgemen
t
Set/Get
0: ON
1: OFF
120 With rotation Set/Get
0: OFF
1: ON
121
Upper limit of the rotation
an
gle
Set/Get -180 to 180
122
Lower limit of the rotation
an
gle
Set
/Get -180 to 180
123 Edge level (model) Set/Get 0 to 1024
124 Reverse Set/Get
0: Do not allow black and white reverse
1: Allow black and white reverse
126 High-Prec. Set/Get
0: OFF
1: ON
127 Reference X
*2
Set/Get 0 to 99999.9999
128 Reference Y
*2
Set/Get 0 to 99999.9999
129 Reference angle θ Set/Get -180.0 to 180.0
130 With/without size change Set/Get
0: OFF
1: ON
131
Upper limit of the size
chan
ge
Set
/Get 50 to 200(%)
132
Lower limit of the size
chan
ge
Set
/Get 50 to 200(%)
133 Candidate Point Level Set/Get 0 to 100
134 Detection point X Set/Get 0.0000 to 9999.0000
