Shape Search III
188
FH/FZ5 Processing Item Function Reference Manual
135 Detection point Y Set/Get 0.0000 to 9999.0000
136 Sort condition Set/Get
0: Correlation value ascending
1: Correlation value descending
2: Measurement coordinate X ascending
3: Measurement coordinate X descending
4: Measurement coordinate Y ascending
5: Measurement coordinate Y descending
137 Search No. Set/Get 0 to 127
138
Judgement upper limit for
correlation value
Set/Get 0 to 100
139
Judgement lower limit for
correlation value
Set/Get 0 to 100
140
Judgement upper limit for
nu
mber of detections
Set/Get 0 to 128
141
Judgement lower limit for
nu
mb
er of detections
Set/Get 0 to 128
142
Judgement upper limit for
me
a
surement coordinate
X
Set/Get -99999.9999 to 99999.9999
143
Judgement lower limit for
mea
surement coordinate
X
Set/Get -99999.9999 to 99999.9999
144
Judgement upper limit for
mea
surement coordinate
Y
Set/Get -99999.9999 to 99999.9999
145
Judgement lower limit for
measurement coordinate
Y
Set/Get -99999.9999 to 99999.9999
146
Judgement upper limit for
me
a
surement angle
Set/Get -180 to 180
147
Judgement lower limit for
me
a
surement angle
Set/Get -180 to 180
150
Edge level
(measure
m
ent)
Set/Get 0 to 1024
161 Count Set/Get 0 to 128
168 Multiple output Set/Get
0: OFF
1: ON
171 Save registered model Set/Get
0: None
1: Save
172
Edge level
(measurem
ent)
auto setting
Set/Get
0: OFF
1: ON
173
High-speed alignment
mode
Set/Get
0: OFF
1: ON
174 Filter size Set/Get
0: 3 × 3
1: 5 × 5
2: 7 × 7
177 Smoothing level Set/Get 1 to 16
178
Edge level (model)
auto setting
Set/Get
0: OFF
1: ON
No. Data name Set/Get Data range
