FH/FZ5 Processing Item Function Reference Manual
External Reference Tables (Iris)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
1 Count Get only 0 to 100
2 Average Get only ---
3 Average R component value Get only 0 to 255
4 Average G component value Get only 0 to 255
5 Average B component value Get only 0 to 255
6 Recent count Get only ---
7 Recent average Get only ---
8 Recent average R Get only ---
9 Recent average G Get only ---
10 Recent average B Get only ---
103 Reflect to overall judgement Set/Get
0: ON
1: OFF
120 Brightness range Min. Set/Get 0 to 255
121 Brightness range Max. Set/Get 0 to 255
122 In range Min. Set/Get 0 to 100
123 Average Min. Set/Get 0 to 255.0
124 Average Max. Set/Get 0 to 255.0
125 R average Min. Set/Get 0 to 255.0
126 R average Max. Set/Get 0 to 255.0
127 G average Min. Set/Get 0 to 255.0
128 G average Max. Set/Get 0 to 255.0
129 B average Min. Set/Get 0 to 255.0
130 B average Max. Set/Get 0 to 255.0
