Machine Simulator
554
FH/FZ5 Processing Item Function Reference Manual
Key Points for Test Measurement and Adjustment (Machine Simulator)
The image specified in the Sub-image number in image display setting is displayed in the image display area.
Key Points for Adjustment
Adjust the setting parameters referring to the following points.
The image is not compensated correctly
Other
Measurement Results for Which Output Is Possible (Machine Simulator)
The following values can be output using processing items related to results output. It is also possible to refer to
measurement values from expressions and other processing units.
Sub image. Explanation of image to be displayed
0, 2 to 31 Measurement image (Same when a list of positions is displayed)
1 Input image
State Parameter to be adjusted Troubleshooting
The corrected image is
completely different
Actual setting
The conditions for the actual coordinate system (origin position,
mag
n
ification, axis angle) may not be set correctly. Check for input
errors. In factory default, the real coordination system is same as
the camera coordination.
The corrected image is
sl
ightly dif
ferent
Movement setting
The current axis position may not be set correctly. Set this
con
d
ition when simulating a movement from other than the origin
return position. The current axis position is a parameter required
for accurate calculation of the travel distance of the actuator.
State Parameter to be adjusted Troubleshooting
The reference unit number
is
<"None"> and
cannot be selected.
Machine setting
Check if the reference scene number is selected
correctly.
Check if stage data processing items or robot data processing
items are registere
d in the selected reference scene.
The reference unit number
does not change during
flow editing.
Machine setting
The system is designed this way.
While a scene other than the current scene is referenced, the
referen
ce unit number does not change according to the editing of
the flow. Change the flow so that the current scene will be
referenced, or set the reference unit number again.
Measurement items Character string Description
Judge JG Judgment result
