FH/FZ5 Processing Item Function Reference Manual
Output Parameters (Intersection)
Set how to treat the coordinates to be output to the external device as measurement results. This item can be
changed if necessary.
1 Click [Output parameter] in the Item Tab area.
2 Specify each of the following items.
Key Points for Test Measurement and Adjustment (Intersection)
The following content is displayed in the "Detail result" area as text.
Key Points for Adjustment
Select the adjustment method referring to the following points.
When the measurement results are unstable
When judgement is NG
• After setting up the measurement parameters, changing the output parameters will cause measurement results to vary
accordingly. If the output parameters have been changed, re-specify the measurement, too.
Setting item
Setting value
[Factory default]
Description
Output coordinates
• [After scroll]
• Before scroll
As measurement results, select whether
to output coordinate values to
external devices before or after the position compensation is applied.
Calibration
•[OFF]
•ON
Select whether to reflect the calibration in the values output to the
external
device as measurement results.
ON: Output the coordinates converted into actual dimensions.
OFF: Output the camera coordinate values.
Reflect to overall
ju
dgemen
t
•[ON]
•OFF
Specify whether or not the judgement results of this processing unit is
reflected in the scene overall judgement.
Displayed items Description
Judge Judgement result
Intersection coordinate X X coordinate of measured intersection
Intersection coordinate Y Y coordinate of measured intersection
Angle Angle of measured 2 lines
Lost point count (line 0) Lost point count of measured line 0
Lost point count (line 1) Lost point count of measured line 1
State Parameter to be adjusted Troubleshooting
Approximate lines are not
stab
le due to noise.
Measurement
Use the noise removal function to make sure approximate lines
are
measured stably.
Parameter to be adjusted Troubleshooting
Region setting
Confirm that the approximate line calculated for line
0 intersects with the approximate line
calculated for line 1. If the approximate lines are parallel, a judgement will be NG.
