Precise Defect
376
FH/FZ5 Processing Item Function Reference Manual
Output Parameters (Precise Defect)
Specifies whether or not the judgement results of this processing unit is reflected in the scene overall judgement.
1 Click [Output parameter] in the Item Tab area.
2 Choose whether or not to reflect this in the scene overall judgement in "Reflect to overall
judgement" area.
Key Points for Test Measurement and Adjustment (Precise Defect)
The following content is displayed in the "Detail result" area as text.
The image specified in the Sub-image number in image display setting is displayed in the Image Display area.
Key Points for Adjustment
Select the adjustment method referring to the following points.
When the measurement results are unstable
Noise is detected as defects.
Judgement will be NG.
When the processing speed is slow
Setting item
Set value
[Factory default]
Description
Reflect to overall
judgement
•[ON]
•OFF
Enables choosing whether or not the judgement results of this processing
unit is reflected in the scene overall judgement.
Displayed items Description
Judge Judgement result
Defect value Measured defect level
Position X X Coordinate of measured defect position
Position Y Y coordinate of measured defect position
Defect Area The measured maximum defect area
Gravity X The center of gravity X coordinates of
the
measured maximum defect area
Gravity Y The center of gravity Y coordinates of the
measured maximum defect area
Defect number Number of measured defects
Sub image number Explanation of image to be displayed
0 Measurement image
1
Defect profile [when area measu
rement is present]
If the region display is enabled, the defect area display image specified [when no area measurement].
Parameter to be adjusted Remedy
Measurement Specify a larger value for "Defect judge" in the judgement conditions.
Parameter to be adjusted Remedy
Measurement Make the measurement region larger than the value of the el
ement size.
Parameter to be adjusted Remedy
Measurement Specify a larger value for the element creation interval.
