Control Flow Parallel
856
FH/FZ5 Processing Item Function Reference Manual
Measurement Results for Which Output Is Possible (Control Flow Parallel)
The measurement results provided by control flow parallel are shown below. The measurement results appear in
the “Detail Result” area, and you can also use result output processing items to output the measurement results
to an external device.
Refer to the “External Reference Tables” for the parameter
s
that can be referenced, including measurement
results.
(Reference: External Reference Table (Control Flow Parallel) (p.856))
External Reference Table (Control Flow Parallel)
By specifying a number, you can access the following data from processing items that support processing unit
data setting/acquisition, and from control commands.
Measurement item Character string Description
Judge JG The judgement result for the processing unit
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 State Get only
0: Flow not stopped
1: Flow stopped
103 Reflect to the overall judgement Set/Get
0: ON
1: OFF
120 Timeout Set/Get
0: Not used
1: Used
121 Timeout time (ms) Set/Get Timeout time (0 to 120,000)
122 WAIT signal Set/Get
0: Not used
1: Used
123 WAIT signal number Set/Get 0 to 15
124 FLG signal Set/Get
0: Not used
1: Used
125 FLG signal number Set/Get 0 to 15
126 Unit judgement in timeout Set/Get
0: NG
1: OK
5000 Wait state clear command Set only 1: Clear the wait state
