Conditional Branch
836
FH/FZ5 Processing Item Function Reference Manual
Measurement Results for Which Output Is Possible (Conditional Branch)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Conditional Branch)
Measurement items Character string Description
Judge JG Judgement result
Expression A result D0 Operational result of expression selected in expression A
Expression B result D1 Operational result of expression selected in expression B
Comparison result RS Result from comparing the expressions (0: NO, 1: YES)
Destination unit No. BU Unit No. at destination based on the comp
ares results of expressions
No. Data name Set/Get Data range
0 Judge Get
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Expression A result Get
Maximum 256 characters (result of calculation selected in
e
x
pression A)
6 Expression B result Get
Maximum 256 characters (result of calculation selected in
e
xpression B)
7 Comparison result Get
0: NO
1: YES
8 Destination unit No. Get 0 to 32767
120 Condition type Set/Get
0: A = B
1: A ≤ B
2: A < B
3: A ≥ B
4: A > B
121
YES branch destination
Un
it No.
Set/Get
-1: End processing
0 to 32767: unit No.
122 NO Destination Unit No. Set/Get
-1: End processing
0 to 32767: unit No.
123 Expression A Set/Get Expression character string
124 Expression B Set/Get Expression character string
125 Timeout Set/Get
0: Not used
1: Used
126 Timeout time [s] Set/Get 1 to 3600
