Vision Master CalibrationFH/FZ5 Processing Item Function Reference Manual
763
4
Support Inspection and Measurement
Measurement Results for Which Output Is Possible (Vision Master Calibration)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Vision Master Calibration)
Measurement items
Character
string
Description
Judge JG Judgement result
Origin return output flag ORIF Origin return output flag
Calibration end flag ENDF Calibration completion output flag
Error evaluation value X EX Error evaluation value X
Error detection value Y EY Error detection value Y
Next X axis movement NMX Next X axis movement amount
Next Y axis movement NMY Next Y axis movement amount
Next θ axis ang
le movement NMT Next θ axis angle movement amount
Next θ axis linear mo
vement NML Next θ axis linear movement amount
Next U axis movement NMU Next U axis movement amount
Next V axis movement NMV Next V axis movement amount
Next W axis movement NMW Next W axis movement amount
Next R axis movement NMR Next R axis movement amount
NG cause CNG
NG cause
-1: Setting NG
-2: Sequence NG
-3: Mobility NG
-4: Calibration NG
-5: Evaluation NG
-6: Sampling NG
-100: Other NG
Measurement execution flag MF Measurement execution flag
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement(unmeasured)
1: Judgement result OK
-1: Judgement result NG
6 Origin return flag Get only 0 to 1
7 Calibration end flag Get only 0 to 1
10 Next X-axis Movement Get only -
11 Next Y-axis Movement Get only -
12 Next θ-axis Movement Get only -
13 Next θ-axis (Linear Dr
ive) Movement Get only -
14 Next U-axis Movement Get only -
15 Next V-axis Movement Get only -
16 Next W-axis Movement Get only -
17 Next R-axis Movement Get only -
18 Next Calibration Operation Get only -
