Trapezoidal CorrectionFH/FZ5 Processing Item Function Reference Manual
549
3
Compensate image
External Reference Tables (Trapezoidal Correction)
*1: Numerical data can also be set in the data setting processing items for the processing unit, etc.
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
120 Interpolation mode Set/Get
0: None
1: Linear interpolation
121 Method Set/Get
0: See unit 4
1: Expression
122 Input image Set/Get
0: Camera image
1: Prev image
123
Reference position setting
method
Set/Get
0: Figure
1: Expression
124
Measurement position
setti
ng method
Set/
Get
0: Figure
1: Expression
125
Reference coordinate
di
splay
Set/Get
0 : Not displayed
1 : Displayed
126
Reference coordinate
dis
p
lay color
Set/Get
0: Black
1 : White
2: Red
3: Green
4: Blue
127
Measurement coordinate
di
splay
Set/Get
0 : Not displayed
1 : Displayed
128
Measurement coordinate
dis
play color
Set/Get
0: Black
1 : White
2: Red
3: Green
4: Blue
129 Filtered image Set/Get
0: Disp input image
1: Filtered image
200 + N (N = 0 to 3)
X coordinate of the
re
fe
rence coordinate N
Set/Get Character string for expression (*
1
)
300 + N (N=0 to 3)
Y coordinate of the
refe
rence coordinate N
Set/Get Character string for expression (*
1
)
400 + N (N = 0 to 3)
X coordinate of the
measurement coordinate N
Set/Get Character string for expression (*
1
)
500 + N (N = 0 to 3)
Y coordinate of the
mea
surement coordinate N
Set/Get Character string for expression (*
1
)
