Set Unit FigureFH/FZ5 Processing Item Function Reference Manual
657
4
Support Inspection and Measurement
Measurement Results for Which Output Is Possible (Set Unit Figure)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Set Unit Figure)
Measurement items Character string Description
Judge JG The latest processing unit judgement result
Number of data items DNO Number of data items setup
Data 0 DT0 Calculation result of setup data 0
Data 1 DT1 Calculation result of setup data 1
Data 2 DT2 Calculation result of setup data 2
Data 3 DT3 Calculation result of setup data 3
Data 4 DT4 Calculation result of setup data 4
Data 5 DT5 Calculation result of setup data 5
Data 6 DT6 Calculation result of setup data 6
Data 7 DT7 Calculation result of setup data 7
Data 8 DT8 Calculation result of setup data 8
Data 9 DT9 Calculation result of setup data 9
Data 10 DT10 Calculation result of setup data 10
Data 11 DT11 Calculation result of setup data 11
Data 12 DT12 Calculation result of setup data 12
Data 13 DT13 Calculation result of setup data 13
Data 14 DT14 Calculation result of setup data 14
Data 15 DT15 Calculation result of setup data 15
Data 16 DT16 Calculation result of setup data 16
Data 17 DT17 Calculation result of setup data 17
Data 18 DT18 Calculation result of setup data 18
Data 19 DT19 Calculation result of setup data 19
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (un measured)
1: Judgement result OK
-1: Judgement result NG
5 to 24 Data 0 to 19 Get only -999999999.9999 to 999999999.9999
120 Ta rg et unit Set/Get 0 to 9999
121 Register figure No. Set/Get 0 to 999
122 Target figure No. Set/Get 0 to 7
123
Number of setting data
items
Get only 0 to 20
