Polar Transformation
542
FH/FZ5 Processing Item Function Reference Manual
Key Points for Test Measurement and Adjustment (Polar Transformation)
The image specified in the Sub-image number in image display setting is displayed in the image display area.
Measurement Results for Which Output Is Possible (Polar Transformation)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Polar Transformation)
Sub image number Explanation of image to be displayed
0 Post-conversion image
1 Measurement image
Measurement items Character string Description
Judge JG Judgement result
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
120 Cut out angle Set/Get 0 to 359
122 Overlap Set/Get 0 to 360
123 Disp transferred image Set/Get
0: Image prior to transfer
1: Image after transfer
