Scan Edge Position
254
FH/FZ5 Processing Item Function Reference Manual
Key Points for Adjustment
Select the adjustment method referring to the following points.
When the measurement results are unstable
Measurement Results for Which Output Is Possible (Scan Edge Position)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
Parameter to be adjusted Remedy
Measurement
If the color of the edges to be detected is decided, spe
cify the color with [Edge color]. If results
are not stable even with the color specified, specify a larger value for the color variance range.
If noise is detected as an edge, specify larger valu
es
for "Noise level" and "Noise width".
Measurement items Character string Description
Judgement JG Judgement result
Peak edge position X PEAKX
X coordinate of the edge that is the furthest from the start point of the
measureme
n
t region
Peak edge position Y PEAKY
Y coordinate of the edge that is the furthest from the start point of the
measureme
n
t region
Bottom edge position X BOTTOMX
X coordinate of the edge that is the closest to the start point of the
measureme
n
t region
Bottom edge position Y BOTTOMY
Y coordinate of the edge that is the closest to the start point of the
measureme
nt region
Edge position X Ave. X The average of X coordinates of all the edges
Edge position Y Ave. Y The average of Y coordinates of all the edges
Reference coordinate SX X coordinate of the reference coordinates
Reference coordinate SY Y coordinate of the reference coordinates
Long distance Max. PMAXD
The maximum distance between the approximate line and edge position
(plus dir
ection)
Long distance Min. PMIND
The minimum distance between the approximate line and the edge
positio
n (plus direction)
Short distance Max. BMAXD
The maximum distance between the approximate line and the edge
positio
n (min
us direction)
Short distance Min. BMIND
The minimum distance between the approximate line and the edge
positio
n (min
us direction)
Deviation DEV Deviations in concavity and convexity
Angle TH The straight line's inclination again
st the measurement region
Lost point count LOST Number of parts for which the detection of edges has failed
Line Param. A A A in the expression for the approximate line AX + BY + C = 0.
Line Param. B B B in the expression for the approximate line AX + BY + C = 0.
Line Param.C C C in the expression for the approximate line AX + BY + C = 0.
